Reborn 2 Open source drawings:
2. Core X-Y Structure
More high printing speed thanks to super low motion inertial.
3. Super less rate hose blockage
Hose inner wall 0.2um roughness, reduce the blockage rate to insure
4. The high running accuracy
The XYZ shafts are all linear guides to improve the running accuracy
5. There are 2 verisions heating bed with 220V, and heating bed with 110V Silicone Heating Bed, US, MX, CA and Japan is send by 11OV heating bed.
The hot bed was heated with 220v, or 110v silicone, faster heating speed and more uniform.
6. The Newest Design Extruder
Direct extruder, reduced extruder distance, for more high extruder precision
Cleaning filament Easily, Removable feeding hole clean the blocked filament inside easily
More High Extruder Reduction Ratio, The Ratio keeps to 1:7.5, More fast and stable extruder results
Real-time observation，Transparent extruder，watching and checking the extrusion status directly
Dual cooling fan, improving the model surface printing quality.
7. TMC2209 Drive
The extruder Motor adopts tmc2209 drive to bring higher quality printing.
8. Colorful touch screen
High sensitive screen operating, comfortable and simple to use.
9. Wi-Fi connection Function
the way users upload printing file fast and simple
10. Filament run-out Sensor
The runout sensor function, will automatically Pause when filament out or break.
11. The Resume printing
the printer can keep printing if the power failure, less worries about the power off.
12. Easy and fast installation
80% of the accessories have been Pre-installed, come with detailed installation videos are attached, just spend several minutes to start your printing easily
13. Foldable Insulation Cover
Adjustable temperature fan inside，helps to all Filament printing in a good warm keeping condition，as well as ABS filament also printing easily.
Printing size: 325*325*350mm
Bed size: 329*329mm
Printer size: 525*558*595mm
Layer thickness precision: 0.05-0.3
MAX printing speed: 150 mm/s.
Material type: PLA/ ABS/TPU/SILK/PETG/PA/PC/NYLON
Material specifications : 1.75mm in diameter.
Positioning accuracy: Z 0.002mm, XY 0.01mm.
Nozzle diameter: 0.4mm
Hotend temperature: 350℃
Hot bed temperature: 60-110deg℃.
Extruder number: 1
Power requirements: 24V, 300W
Connectivity: WiFi, TF card, USB
Input file format: STL , OBJ , DAE , AMF
Output file format: GCode
Compatibility: Windows, Mac.
Control software: Cura.
Machine weight: 20.3(kg)
Package weight: 22.5(kg)
I like the design very much and the price/performance ratio is great for a printer of this size. With Klipper and some mods this thing can fly.
This printer has a solid value for what you get out of the box it prints well nice frame and extruder. IF YOU TINKER , you can get this machine to FLY.
If your looking for a large format cover xy and you like to learn more and tinker then this is a bargin. If you do a few mods like Klipper on this machine it will be excellent. Checkout youtube for all the reviews !!
The Flying Bear Reborn 2 provides great prints at a very reasonable price point. The z-axis is rock solid and holds a level well. The PEI sheet and ABL sensor are low cost additions that provide a great experience. They both work great and I was impressed with the quality of the prints I am getting from the printer. Definitely a great addition to my collection.
First my background: 20+ years as Tech Designer / Prototyper. This my 4th Printer, (Anycubic Vyper, Lulzbot TAZ 5 & Mini 2). I consider myself an Intermediate User.
I find the FB Reborn 2 to be an excellent Printer. Frame construction is very sound. The sum of tight tolerances, interlocking parts, oversize belts and Guide Rails make for a most rigid machine. The copious use of injection molded parts & metal components puts this CoreXY machine in a Light Industiral capacity.
Simple-to-use underside adjustment knobs make setting up the (all important First Layer) Platform Leveling straight forward, provided you take the time to adjust p-r-e-c-i-s-e-l-y over several passes.
The Interface is easy to use and the Bed & Nozzle heats up quickly. Build layers are clean & sharp.
I am presently fine-tuning Surface Finishes in Ultima CURA 4.13.0 to good effect.
Their Customer Service has already been responsive & helpful in addressing questions.
In summation, I could not build this solid of a Printer for the purchase price & free shipping of a 44lb machine. Overall this is actually a nice printer and highly recommended. Jeff A - Idaho Design & Protoype
For the price, this is the printer to get. With a little work its even better. I am very pleased with my purchase. I should note that the accessory ordered with the printer ships separate. I was a bit confused when two tracking #s were supplied. I checked all the domestic shipping company's and only one#(the printer) could be located. I contacted support via chat and they were very helpful. Both packages arrived in great condition I would buy again.
